Returning

I Remembered

After my last blog post I was so exhausted I had to take a week off, but I’m back. In the course of my blog-free week, I remembered the secret to blogging: blog before I start real work for the day.

It seems obvious, but once that code starts flowing, the prose ain’t coming.

Updates

It’s been a busy couple weeks.

As I mentioned, I’ve been working on getting zink running on an Adreno chromebook using turnip—the open source Qualcomm driver. When I first fired up a CTS run, I was at well over 5000 failures. Today, two weeks later, that number is closer to 150. Performance in SuperTuxKart, the only app I have that’s supposed to run well, is a bit lacking, but it’s unclear whether this is anything related to zink. Details to come in future posts.

Some time ago I implemented dmabuf support for lavapipe. This is finally landing, assuming CI doesn’t get lost at the pub on the way to ramming the patches into the repo. Enjoy running Vulkan-based display servers in style. I’m still waiting on Cyberpunk to finish loading, but I’m planning to test out a full lavapipe system once I finish the game.

Also in lavapipe-land, 1.3 conformance submissions are pending. While 1.2 conformance went through and was blogged about to great acclaim, this unfortunately can’t be listed in main or a current release since the driver has 1.2 conformance but advertises 1.3 support. The goalpost is moving, but we’ve got our hustle shoes on.

Real Work

On occasion I manage to get real work done. A couple weeks ago, in the course of working on turnip support, I discovered something terrible: Qualcomm has no 64bit shader support.

This is different from old-time ANV, where 64bit support isn’t in the hardware but is still handled correctly in the backend and so everything works even if I clumsily fumble some dmat3 types into the GPU. On Qualcomm, such tomfoolery is Not Appreciated and will either fail or just crash altogether.

So how well did 64bit -> 32bit conversions work in zink?

Not well.

Very not well.

A Plethora Of Failures

Before I get into all the methods by which zink fails, let’s talk about it at a conceptual level: what 64bit operations are needed here?

There are two types of 64bit shader operations, Int64 and Float64. At the API level, these correspond to doing 64bit integer and 64bit float operations respectively. At the functional level, however, they’re a bit different. Due to how zink handles shader i/o, Int64 is what determines support for 64bit descriptor interfaces as well as cross-stage interfaces. Float64 is solely for handling ALU operations involving 64bit floating point values.

With that in mind, let’s take a look at all the ways this failed:

  • 64bit UBO loads
  • 64bit SSBO loads
  • 64bit SSBO stores
  • 64bit shared memory loads
  • 64bit shared memory stores
  • 64bit variable loads
  • 64bit variable stores
  • 64bit XFB stores

Basically everything.

Oops.

Fixing: Part One

There’s a lot of code involved in addressing all these issues, so rather than delving too deeply into it (you can see the MR here), I’ll go over the issues at a pseudo code level.

Like a whiteboard section of an interview.

Except useful.

First, let’s take a look at descriptor handling. This is:

  • 64bit UBO loads
  • 64bit SSBO loads
  • 64bit SSBO stores
  • 64bit shared memory loads
  • 64bit shared memory stores

All of these are handled in two phases. Initially, the load/store operation is rewritten. This involves two steps:

  • rewrite the offset of the operation in terms of dwords rather than bytes (zink loads array<uint> variables)
  • rewrite 64bit operations to 2x32 if 64bit support is not present

As expected, at least one of these was broken in various ways.

Offset handling was, generally speaking, fine. I got something right.

What I didn’t get right, however, was the 64bit rewrites. While certain operations were being converted, I had (somehow) failed to catch the case of missing Int64 support as a place where such conversions were required, and so the rewrites weren’t being done. With that fixed, I discovered even more issues:

  • more 64bit operations were being added in the course of converting from 64bit to 32bit
  • non-scalar loads/stores broke lots of things

The first issue was simple to fix: instead of doing manual bitshifts and casts, use NIR intrinsics like nir_op_pack_64_2x32 to handle rewrites since these can be optimized out upon meeting a matching nir_op_unpack_64_2x32 later on.

The second issue was a little trickier, but it mostly just amounted to forcing scalarization during the rewrite process to avoid issues.

Except there were other issues, because of course there were.

Some of the optimization passes required for all this to work properly weren’t handling atomic load/store ops correctly and were deleting loads that occurred after atomic stores. This spawned a massive amount of galaxy brain-level discussion that culminated in some patches that might land someday.

So with all this solved, there were only a couple issues remaining.

How hard could it be?

FFFFFFFUUUUUUUUUUUU

Anyway, so there were more issues, but really it was just two issues:

  • 64bit shader variable handling
  • 64bit XFB handling

Tackling the first issue first, the way I saw it, 64bit variables had to be rewritten into expanded (e.g., dvec2 -> vec4) types and then load/store operations had to be rewritten to split the values up and write to those types. My plan for this was:

  • scan the shader for variables containing 64bit types
  • rewrite the type for a matching variable
  • rewrite the i/o for matching variable to use the new type

This obviously hit a snag with the larger types (e.g., dvec3, dvec4) where there was more than a vec4 of expanded components. I ended up converting these to a struct containing vec4 members that could then be indexed based on the offset of the original load.

But hold on, Jason “I’m literally writing an NVIDIA compiler as I read your blog post” Ekstrand is probably thinking, what about even bigger types, like dmat3?

I’m so glad you asked, Jason.

The difference with a 64bit matrix type is that it’s treated as an array<dvec> by NIR, which means that the access chain goes something like:

  • deref var
  • deref array (row/column)
  • load/store

That intermediate step means indexing from a struct isn’t going to work since the array index might not be constant.

It’s not going to work, right?


It turns out that if you use the phi, anything is possible.

Here’s a taste of how 64bit matrix loads are handled:

/* matrix types always come from array (row) derefs */
assert(deref->deref_type == nir_deref_type_array);
nir_deref_instr *var_deref = nir_deref_instr_parent(deref);
/* let optimization clean up consts later */
nir_ssa_def *index = deref->arr.index.ssa;
/* this might be an indirect array index:
 * - iterate over matrix columns
 * - add if blocks for each column
 * - phi the loads using the array index
 */
unsigned cols = glsl_get_matrix_columns(matrix);
nir_ssa_def *dests[4];
for (unsigned idx = 0; idx < cols; idx++) {
   /* don't add an if for the final row: this will be handled in the else */
   if (idx < cols - 1)
      nir_push_if(&b, nir_ieq_imm(&b, index, idx));
   unsigned vec_components = glsl_get_vector_elements(matrix);
   /* always clamp dvec3 to 4 components */
   if (vec_components == 3)
      vec_components = 4;
   unsigned start_component = idx * vec_components * 2;
   /* struct member */
   unsigned member = start_component / 4;
   /* number of components remaining */
   unsigned remaining = num_components;
   /* component index */
   unsigned comp_idx = 0;
   for (unsigned i = 0; i < num_components; member++) {
      assert(member < glsl_get_length(var_deref->type));
      nir_deref_instr *strct = nir_build_deref_struct(&b, var_deref, member);
      nir_ssa_def *load = nir_load_deref(&b, strct);
      unsigned incr = MIN2(remaining, 4);
      /* repack the loads to 64bit */
      for (unsigned c = 0; c < incr / 2; c++, comp_idx++)
         comp[comp_idx] = nir_pack_64_2x32(&b, nir_channels(&b, load, BITFIELD_RANGE(c * 2, 2)));
      remaining -= incr;
      i += incr;
   }
   dest = dests[idx] = nir_vec(&b, comp, intr->num_components);
   if (idx < cols - 1)
      nir_push_else(&b, NULL);
}
/* loop over all the if blocks that were made, pop them, and phi the loaded+packed results */
for (unsigned idx = cols - 1; idx >= 1; idx--) {
   nir_pop_if(&b, NULL);
   dest = nir_if_phi(&b, dests[idx - 1], dest);
}

I just saw Big Triangle reaching for a phone, probably to call the police regarding illegal amounts of compiler horseplay, so let’s move on so I can maybe finish this before I get hauled off.

The only remaining issue now is

FFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFFF

Look, there’s a reason why entire blog posts are devoted to the awfulness of XFB.

It’s bad.

Really bad.

I’m not going to go deep into the changes required. They’re terrible. The gist of it is that zink utilizes two mechanisms to handle XFB, and one is worse than the other. That one is the “manual emission” handler, in which the output of a variable is read back and then explicitly stored to an XFB output. This has to handle all the variable types (in spirv) for both the load and the store, and then it also has to untangle the abomination that is Gallium XFB handling, and it’s just terrible.

But it’s done.

And with it comes the marking off of a ton of CTS failures for turnip and other platforms that lack 32bit support.

Written on June 7, 2022
